FLS Series
FLS 48100SG2
40.96kwh
100h
Low voltage
Wall mounted/floor mounted
Built-in Wi-Fi
Protection level IP21
Product introduction
FLS48100SG2 is equipped with a lithium iron phosphate battery designed for home use. Developed based on customer needs and market demands, this advanced energy storage system provides high quality and reliable power for various devices. The product offers long life, excellent performance in high temperature environments and a compact design that requires minimal installation space.
FLS48100SG2 incorporates a battery management system independently developed by our team. When connected to the grid or a photovoltaic system as a power source, the product can store energy by charging the battery. In the event of a power outage from the grid or photovoltaic system, the product supplies electricity independently to household loads. In addition, multiple units can be connected in parallel to form a large-capacity, multi-module system, meeting long-term energy storage requirements.
FLS48100SG2 incorporates a battery management system independently developed by our team. When connected to the grid or a photovoltaic system as a power source, the product can store energy by charging the battery. In the event of a power outage from the grid or photovoltaic system, the product supplies electricity independently to household loads. In addition, multiple units can be connected in parallel to form a large-capacity, multi-module system, meeting long-term energy storage requirements.
Product advantages
• LiFePO4: Greater safety and longer useful life.
• Multiple protection: Built-in smart BMS, circuit breaker and fuse.
• Flexible installation: Wall or floor mounting.
• Wide compatibility: Compatible with the main brands of inverters.
• High scalability: Capacity up to 40.96kWh.
• Equipped with an aerosol fire extinguishing system.
• When the battery experiences overcurrent causing the fuse to break, the fuse can be easily replaced from the outside, providing great convenience.
• Multiple protection: Built-in smart BMS, circuit breaker and fuse.
• Flexible installation: Wall or floor mounting.
• Wide compatibility: Compatible with the main brands of inverters.
• High scalability: Capacity up to 40.96kWh.
• Equipped with an aerosol fire extinguishing system.
• When the battery experiences overcurrent causing the fuse to break, the fuse can be easily replaced from the outside, providing great convenience.
Model
FLS48100SG2
Operating voltage
44.8-57.6V
Number of battery modules
8
Energy
40.96kWh
Scalability
Up to 8 units in parallel (40.96kwh)
Depth of Discharge (DoD)
≥95%
Bicycle life
≥6,000 cycles
Communication
RS485/CAN
Protection level
IP21
Discharge
FLS48100SCG2
- [UN38.3 TEST Summary] 1125003993-2 FLS48100SCG2
- [UN38.3 TEST REPORT] 1125003993Y-1 FLS48100SCG2
- [MSDS] 1125003993-4 FLS48100SCG2
- [Hazard Information Label] 1125003993-5 FLS48100SCG2
- [Certification for Classify of Danger of Batteries] 1125003993-3 FLS48100SCG2
- [Certificate for Safe Transport of Goods by Sea] 1125003993-6 FLS48100SCG2
- [Certificate for Safe Transport of Goods by Road] 1125003993-7 FLS48100SCG2
FLS48100SMG2
- [UN38.3 TEST Summary] 1125003992-2 FLS48100SMG2
- [UN38.3 TEST REPORT] 1125003992Y-1 FLS48100SMG2
- [MSDS] 1125003992-4 FLS48100SMG2
- [Hazard Information Label] 1125003992-5 FLS48100SMG2
- [Certification for Classify of Danger of Batteries] 1125003992-3 FLS48100SMG2
- [Certificate for Safe Transport of Goods by Sea] 1125003992-6 FLS48100SMG2
- [Certificate for Safe Transport of Goods by Road] 1125003992-7 FLS48100SMG2
